Experimental facilities





Electron microscopy

University of Aveiro:

Scanning Electron Microscope: HR-FESEM Hitachi SU-7 (Hitachi)

Transmission Electron Microscopes: HR-(EF)TEM-JEOL 2200 FS and TEM FE 200kVb (JEOL)



University of Bern:

Hitachi S-3000 N



Ruhr-University Bochum:

Scanning Electron Microscope:

REM

JEOL JSM-6510 Series

The high-resolution scanning electron microscopes of the JSM-6510 series are cost effective and powerful at the same time. An individually configured, well coordinated user interface makes it easy to get oriented quickly and is intuitive to operate. The Smile Shot™ software offers optimal instrument settings for new or unknown specimens.
A range of effective automatic functions (focus, contrast and brightness, astigmatism correction, source and column adjustments) simplify routine work and make it possible even for novices to quickly achieve optimal results.
In addition, the JSM-6510 series’ microscopes can optionally be equipped with the completely integrated energy dispersive x-ray analysis system. Here imaging and element analysis are performed on one computer within a single user interface. A simple mouse click within the SEM image suffices to perform an element analysis or an element mapping.

Features

  • Super-conical lens for a high image resolution even at low excitation voltages
  • Large specimen chamber for specimens with a diameter up to 150 mm
  • multi sample holder
  • Eucentric specimen stage
  • Smart settings for specimens that must be analyzed frequently
  • Individually configurable toolbars for repeated function sequences
  • Live imaging with up to four detectors simultaneously including picture-in-picture
  • Mixing of different detector signals
  • Integrated video recording of dynamic processes (.avi format)
  • Ultra-compact external dimensions and low installation requirements

Resolution up to 3 nm at 30 keV

Back scattered electron detector for topographical scans.

Air cooled BRUKER EDX detector with the option for line scan and mapping.

TOP



ESR

University of Aveiro:

ESP300E, X band (Bruker).



University of Bern:

Bruker ESR



University of Prague:

Pulse electron spin resonance set-up Bruker (SAFMAT laboratory):

In a magnetic resonance experiment, the position of the resonance lines reflects both local symmetry and degree of lattice distortion around paramagnetic particle. The electron-nuclear interaction determines the nuclear (i.e. chemical) species coupled to the center.



ESR Prag



TOP



Optical spectroscopy

University of Aveiro:

Fluorescence inverted microscope. Axiovert 200 (Zeiss).
Fluorescence Intravital Microscope. Fluocert FU-modified (Leica).
Parallel Flow Confocal Chamber. RC-30WA (Warner Instruments).
UV-Vis Spectrometer. V-560 (Jasco).
Fluorescence spectrometer. Cary Eclipse (Varian).



Fluorimeters (2). FLUROLOG-2 and FLUROLOG-CSPC (Horiba Scientific), UV-Vis-NIR (240-1900 nm) steady state and time-resolved photoluminescence (emission and excitation modes); emission decay curves (timescale: 10-2-10-9 s), in the temperature range 12-450 K. Samples: Films, crystals, powders and liquids.

LuminescenceLuminescence

Photographs of the FLUROLOG-2 equipment. (1) FLUOROLOG-2, (2) vacuum system, (3) He-closed cycle cryostat.

UV/Vis/NIR Spectrophotometer. LAMBDA 950 with 150mm Integrating spheres (Perkin Elmer), UV/Vis/NIR (250-3300 nm) reflectance/transmittance in the temperature range 273-373 K. Samples: Films, crystals, powders and liquids.

UV/Vis



Spectroscopic Ellipsometer. AutoSE (Horiba-Jobin Yvon). Visible (400-800 nm) ellipsometric measurements in the temperature range 273-373 K. Thicknesses and optical constants of thin layers and multi layers.

Ellipsometer



Integrating Spheres (2). C9920-02 (Hamamatsu) and ISP 150L-131 (Instrument Systems). UV-Vis (240-1900 nm) absolute emission quantum yield, radiant power and luminous flux. Samples: Films, crystals, powders and liquids.

Integration sphereIntegration sphere



CCD Calibrated Camera. TOP 100/DTS140-111 (Instrument systems). Radiometric and photometric measurements. Films, crystals and powders.

CCD



NIR Solid State lasers. Operating at 980 nm, 1.0 W, (Thorlabs) and 808 nm, 3.0 W (Crystalasers),.

LASER



Pulsed UV Light Emitting Diodes. Operating at 330 nm, NAnoLED-330, and at 390 nm, NAnoLED-390 with 1.2 ns pulse duration, 1 MHz repetition rate, and 150 ns synchronization delay. (Horiba Scientific).

Peltier temperature programmer. PCB 1500 Water Peltier System (Perkin Elmer). Temperature control between 273 and 373 K.

Peltier

TOP

University of Bern:

Cary 6000 with closed cycle He refrigerator, Fluorolog, Ar+ laser, Kr+ laser, Ti-sapphire laser, various spectrometers, Optical Cryostat



Ruhr-University Bochum:



Cary 5000: UV-Vis and NIR Spectrometer

Cary 5000



The device is able to perform measurements beyond 8.0 absorbance units with reference beam attenuation. Measuremets are possible from 175 to 3300 nm using a PbSmart NIR detector for extended photometric range. Accessoirs for diffuse reflectance. Large sample compartment with LockDown mechanism. Maximum light throughput using Schwarzchild coupling optics. Minimal noise and stray light using a floating aluminum casting and double Littrow monochromator.



Cary 50: UV-Vis and NIR Spectrometer

Cary 50



Horiby Jobin Yvon Fluorolog FL 3-22 spectrometer

Fluorolog



On our Fluorolog FL 3-22 spectrometer (Horiba Jobin Yvon, Unterhachingen, D) fluorescence and phosphorescence measurements can be carried out. A choice between a continuous xenon lamp with 450 W for steady-state luminescence and a pulsed xenon lamp for lifetime and time-resolved measurements is possible. Double gratings for the excitation and emission spectrometer are applied as monochromators. The signal is detected by a photomultiplier. For low temperature measurements (77 K), a Dewar equipped with optical glass windows can be filled with liquid nitrogen. In addition, an Optistat DN-V cryostat is available for precise temperature control.



Opolette laser system

Opolette

With our Opolette-system we are able to excite in the range of 210-2200 nm (optical parametric oscillator). We have three detectors available: Photomultipliers for the visible and near-infrared region, and a stroboscopic fluorescence lifetime spectrometer. In addition, magnetic stirring and injection of additional substances during the measurement is possible for liquid samples.
Besides, two Optel Laser diodes (980 nm/ 100 mA and 808 nm/ 255 mA) are available. A portable Ocean Optics (QE 65000) CCD camera can be used as an additional detector.

TOP

University of Prague:


Shimadzu 3101 PC double beam absorption spectrometer, spectral range 190 – 3500 nm. Adapted for LN bath nitrogen cryostat (Optistat, Oxford Instruments) which allows measurements in 80 – 500 K temperature range.

UV/Vis

Click here or the photo for additional pictures



Luminescence 5000M and “cube” set-up’s, Horiba Jobin Yvon. Spectral range 190 – 800 nm. Excitation D2-lamp, ns and µs flashlamps, nanoLED ns LED sources, X-ray tube, radioisotopes. Temperature range 8 – 500 K
(LN and closed cycle cryostats).

Advanced set-up for the light yield measurement of scintillation materials:

  1. HPMT photodetector
  2. Alpha, beta and gamma radioisotopes in 10 – 5000 keV energy range
  3. Fast memory oscilloscope for decay measurement

Measurement of the light yield, energy resolution and nonproportionality.

Luminescence

Click here or the photo for additional pictures

University of Verona:

Ar laser, Nd-YAG laser, Dye laser, Ti-saphire laser, 980 nm diode laser, CCD and water cooled GaAs photomultiplier for the detection of emitted light, 500 MHz digital oscilloscope for the measurement of emission decay curves, ow temperature cryostat (10 K)





IR/Raman spectroscopy

University of Aveiro:

FT-Raman Spectrometer. RFS 100 (Bruker)
FT-IR Spectrometer. 7000 (Mattson)
ATR Golden Gate Accessory for FT-IR Spectrometer. 7000 (Speckac)



Ruhr University Bochum:

IR Raman

Agiltron Peakseeker Raman and Bruker alpha IR-spectrometers



TOP



NMR

University of Aveiro:

Solid-State NMR Spectrometers (2). Avance 400, 9.4 T and Varian-VNMR600 (Bruker).
Solid/Liquid State NMR Spectrometer. Avance 500, with an ultrashielded static magnetic field (Bruker).
NMR relaxometer. mq20 (Bruker).

TOP



Synthesis

University of Bern:

Glove boxes, vacuum lines, various furnaces, HF apparatus, Bridgman furnaces



Ruhr University Bochum:

Microwave synthesis

Microwave



Torrovap TVP-800 PVD devices

TVP-800

Serial No. 009

TVP-800

Serial No. 001 - The first of its kind

Glove boxes

Gloveboxes

Gloveboxes

Gloveboxes



Vacuum lines

Vacuum lines

Vacuum lines



Synthesis of high purity rare earth halides

Rare Earth halides



Diffusion pump

Diffusion pump

TOP

University of Prague:

Czochralski growth apparatus manufactured by LPA France. RF heating, crucible weighing, closed chamber enabling the growth in various atmospheres even under pressure.

CzochralskiCzochralski



High-temperature furnace model HT 1800-Plus Vac, manufactured by Linn High Term GmbH,  equipped with molybdenum heating elements for annealing in neutral or reducing atmospheres up to approx. 1 600 0C.
Tube or box furnaces for annealing in air up to approx. 1600 0C are also available.

FurnaceFurnace



University of Verona:

4 T-controlled furnaces for heat treatment of samples and crystal growth. Maximum temperature 1500 °C.



Thermoanalysis

University of Bern:

Mettler DSC 823e and TGA/SDTA 851e



Ruhr-University Bochum:

Netzsch DSC-TG

DSC-TG



Netzsch DSC

DSC



TOP



X-ray diffraction

University of Aveiro:

Single-Crystal X-ray Diffractometer. Kappa Apex II (Bruker).
Powder X-ray Diffractometer. Xpert MPD (PANalytical).



University of Bern:

STOE powder diffractometer



Ruhr-University Bochum:

Single crystal diffraction:

IPDS



Powder - XRD

PXRD



University of Verona:

ARL X’TRA powder X-ray diffractometer

TOP



Other equipment

University of Aveiro:

Atomic Force Microscopes (2). AFM Multimode and INTEGRA-NTMDT (VEECO).
Biomolecular Interaction Analyser. BIAffinity-Bioline  (AnalitykJena).
Light Scattering Analyser. Zetasizer Nano ZS (Malver Instruments).
ELISA Multiplate Reader. Multiskan EX (Labsystems).
Flow Cytometer Analysera (2).  FACScalibur-4 scores (Becton-Dickinson) and CyFlow space-7 cores (Partec).
Gas Adsorption Automatic Apparatus. ASAP2010  (Micromeritics).
Magnetic Resonance Imaging (ANIFC). 3.0 Tesla Tim Trio (Siemens).
CO2 Cell Incubator. 5215 (SHEL LAB).
Zeta Potential Analyser.  ZETA pals (Brookhaven Instruments).



Ruhr-University Bochum:

Metrohm Karl-Fischer Coulometry

Karl-Fischer

KF Coulometer with diaphragmless titration cell for water determination right down to trace levels. Can be used to determine water content of liquids, e.g. ionic liquids, and solids from a solution. Display provides information about the relevant titration parameters and gives a presentation of the course of titration in the form of a curve showing µg water against time. At the end of the titration, the value of water content is displayed in ppm. Recommended measuring range: 10 µg...200 mg absolute water.



Polarizing optical microscopy

POM



Ion chromatography:

IC

Our Ion exchange chromatography setup consists of two Metrohm 882 IC Compact Systems, one for cations and one for anions using Metrohm IC Professional MF conductivity detectors. The anion system is equipped with a chemical suppressor (Metrohm MSM, regenerated periodically with 100 mmol/L sulfuric acid) and a carbon dioxide suppressor (Metrohm MCS) for further signal improvement. Also a gradient system (Metrohm Dosino) is available for advanced measurements.

Electroanalysis:

CV

Picture (c) Metrohm GmbH



University of Prague:

X-ray irradiation set-up for the radiation damage study (induced absorption measurement)
X-ray source Seifert, 5 – 60 kW, 3.5 kW in a lead-shielded box.

X ray irradiation X ray irradiation
